InMoov head
Engraved line drawing of InMoov head (assembled and moving): the open-source InMoov i2 design we built. Moving the pointer over the drawing, or the Show in colour button, reveals the true-colour model. Its eyes follow the pointer and keyboard focus, and the Say hi button moves its jaw.
The 3D model shows the InMoov i2 design we built.
Our build of the open-source InMoov i2 head by Gaël Langevin (CC BY-NC 3.0).
The idea & the why
A humanoid robot head whose eyes turn and jaw opens on servos: the open-source, 3D-printable InMoov i2 design, assembled on our bench.
The problem
Expressive robotic movement depends on mechanics and control working together. Eyes and a jaw are a focused way to explore how small motions create a response people understand.
Who it’s for
A research and learning build in humanoid robotics and animatronics, based on Gaël Langevin’s open-source InMoov design.
The thinking behind it
We printed and assembled the InMoov i2 head, then set its eyes and jaw moving on servos.
The result
An expressive humanoid head, assembled on our bench, with eyes that turn and a jaw that opens.
Disciplines
How it’s built
Every part below is read from the model file. Pick a group to pull its parts out of the assembly.
Engraved line drawing of InMoov head: the open-source InMoov i2 design we built, its parts grouped for inspection. Moving the pointer over the drawing, or the Show in colour button, reveals the true-colour model.
54 parts in the model
18 parts in Eyes
- Eye-L-AllPartsV2 times 8
- Eye-L-BaseV5 0
- Eye-R-AllPartsV2 times 8
- Eye-R-BaseV5 0
11 parts in Brows, cheeks & lip
- CheekPullerV3 times 2
- EyebrowSupportV3 0
- EyebrowV3 times 2
- FaceHolderLeftV5 0
- FaceHolderRightV5 0
- ForHeadSupportV2 0
- ForHeadsV4 times 2
- UpperLipV2 0
8 parts in Jaw & teeth
- BottomTeethV1 0
- JawHingeV4 times 2
- JawSupportV2 times 2
- JawV5 0
- TeethTopHolderV3 0
- TopTeethV3 0
11 parts in Skull shells
- EarLockV1 times 2
- LowBackV5 0
- TopBackskullV4 times 2
- TopskullFrontV1 times 4
- TopskullV5 times 2
6 parts in Neck gear & mounts
- GearHolderV3 0
- MainGearV2 0
- PCA9685supportV1 0
- RingV2 0
- ServoGearV2 0
- SkullServoFixV5 0
What we built
- 1. CONCEPTThe idea, modelled in 3D and ready to develop.
- 2. DESIGNEngineered in CAD, part by part, ready to make.
- 3. HARDWAREParts made and assembled into a physical build.
- 4. PROTOTYPE — This projectBuilt, wired and running on the bench.
- What we built
- The full head, printed and assembled on our bench, with servo-driven eyes and jaw.
